Providing basic network services, DHCP and DNS (to be published)
Extra services (to be published, could be splitted in more than one post)
So today’s post will present in order:
Network interfaces configuration
Discussion on what is routing, with activation of packet forwarding, Network Address Translation (NAT) and IP Masquerading
For some items we will see today, we will start with basic functionalities that we will improve or iterate in subsequent posts. As I have said in a previous article, I want to try out nftables instead of using iptables. But many tools I would like to use to quickly create a router are still only supporting iptables as backend, and you cannot mix iptables and nftables. Such tools include systemd-networkd, Docker, or the version of firewalld which Ubuntu is currently supporting (note that firewalld version 0.6+ does support nftables as a backend). So in this first iteration and in order to relatively quickly create a basic router, we will use mostly iptables either through systemd-networkd support or via other tools.
Therefore, we will now see how to build a router from scratch based on Ubuntu 18.04 LTS. I will only configure it for IPv4 as currently my ISP provides only IPv4 connectivity. I am currently planning a series of several posts including that one, I will update that list along the newer articles:
Router features list (this post)
Creating a basic router (to be published, could be splitted in more than one post)
Extra services (to be published, could too be splitted in more than one post)
Disclaimer: I am not a security engineer, although I am very familiar with many aspects of security and security analysis. I am also not a network engineer, although I am very knowledgeable in network protocols, network programming and network security. This article is an exercise for me to see how far I can build a router for SOHO purpose. I make no warranty that it works as intended, nor that I will maintain this article to keep it up to date with respect to network technology and threats. Use at your own risk.
Note: I am mostly going to avoid using any Ubuntu specific tools but of course some will be unavoidable (e.g. network IP address configuration). So this guide should apply to other Linux distributions. Of course there will be some adaptations to do, especially with respect to configuring the network interfaces as there are so many different tools to do that.
Currently my home network is pretty simple … at least for a computer scientist!
My ISP provided an all-in-one box with TV, landline and network router. The latter being very limited and with a crap WiFi access point (AP). So I’ve been using my old Asus RT-AC68U router as a gateway, a 24 ports switch and a Ubiquiti Unifi AP for providing WiFi in the complete house (and garden). The router and switch went into the basement whereas I’ve placed the AP roughly in the house centre. The ISP box could not be configured as bridge but supported to set a DMZ host, so I’ve configure the Asus router to be the DMZ.
